Liquid Biofuels
Liquid Biofuels, also known as biofuels oil, including biodiesel and ethanol, refer to liquid fuels produced by transesterification or catalytic cracking, using animal and vegetable oils(biomass) as feed. Basic materials could be renewable vegetable substances, such as Oil seeds, Soy bean, Palm oil, Corn, Microalgae, etc., or animal fat and oil waste. A liquid biofuel is the liquid part of these substances.

Biomass, including all animals, plants, and microorganisms, refers to various organisms formed by photosynthesis, utilizing atmosphere, water and land. Biomass resources mainly include agricultural and forestry crops, aquatic algae, photosynthetic microorganisms, agricultural and forestry product waste, municipal waste, and livestock waste. All these can be used to produce liquid biofuels, Gaseous biofuels or solid fuels.

Low costs, highly attractive
Biomass is the only clean renewable energy resource that can be liquefied. Biomass oil made from fast pyrolysis of biomass is convenient for being stored and transported with potential to be used as a fossil oil substitute.

The clear advantages of fuels derived from waste products are not only the low price, but they are also environmentally friendly. They are even CO2 neutral, generate considerably less particle emissions than HFO and emit practically no sulphates. This makes them a very attractive source of energy.

Our engines can burn a wide range of substances normally considered as waste. Vegetable oils (such as palm oil, and corn oil, etc.), animal fats, used cooking oil, frying fat and tallow can also be used as fuel for our engines when pre-refined.

All of our medium speed liquid fuel engines can burn liquid biofuels. And our medium speed dual fuel engines are naturally able to burn liquid biofuels in liquid fuel mode as well.

Appendix:Liquid Biofuels Specification

Property/feature

Properties/unit

Test method

 密度 Density/15 °C

 900 - 930 kg/m³

 DIN EN ISO 3675, EN ISO 12185

 闪点 Flash point

 > 60 °C

 DIN EN 22719

 低热值 Lower calorific value

> 35 MJ/kg (typical: 37 MJ/kg)

 DIN 51900-3

 粘度 Viscosity/50° C

 < 40 cSt
(corresponds to viscosity/ 40 °C < 60 cSt)

 DIN EN ISO 3104

 十六烷值 Cetane number

 > 40

 FIA

 焦渣 Coke residue

 < 0.4 %

 DIN EN ISO 10370

 泥沙含量 Sediment content

 < -

 DIN EN 12662

 氧化稳定性 Oxidation stability (110 °C)

 > 5 h

 ISO 6886

 含磷量 Phosphorus content

 < 15 ppm

 ASTM D3231

 Na+K的含量 Na + K content

 < 15 ppm

 DIN 51797-3

 灰份 Ash content

 < 0.01 %

DIN EN ISO 6245

 碘值 Iodine Number

 < 125 g/100g

 DIN EN 14111

 水份 Water content

 < 0.5 %

 EN ISO 12537

 总酸值 TAN (total acid number)

 < 5 mgKOH/g

 DIN EN ISO 660

 冷滤点 Cold Filter Plugging Point

< 10 °C below lowest temperature
in fuel system

 EN 116

Note:
1. All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.
2. For Soar to confirm if the engine can operate using a special type of fuel, please provide a detailed fuel specification.
